SWXFR1230
Switch between inverter power and shore power automatically.
Switch between inverter power and shore power automatically.
Converts 12V battery power to 120V household AC power identical to that supplied by the local utility company. Ideal for running tools and appliances flawlessly while away in your car, truck, boat or RV; and for ensuring motor loads run at optimal efficiency at your remote home or cabin.
Features include:
Features And Benefits
Dimensions (L x W x H):
SWXFR1230: 21.3” x 9.1“ x 4.5” (541 x 231 x 114mm)
Weight:
SWXFR1230: 16.2 lbs. / 7.4 Kg
| POWER (CONTINUOUS) | 3000W |
| POWER (PEAK) | 6000W |
| VOLTAGE / FREQUENCY | 120 VAC / 60 Hz |
| CURRENT | 25.0A |
| WAVEFORM | True Sinewave (<3% THD) |
| PEAK EFFICIENCY | 90% |
| AC RECEPTICLE | NEMA 5-20 x 2 |
| 5V USB | 2.1A |
| VOLTAGE (NOMINAL) | 12.5Vdc |
| OPERATION RANGE | 10.5 – 15.5Vdc |
| INVERTER STANDBY CURRENT | < 1.5A |
| INPUT UNDERVOLTAGE SHUTDOWN | 10.5Vdc |
| INPUT OVERVOLTAGE SHUTDOWN | 15.5Vdc |
| INDICATOR | Status |
| DIGITAL DISPLAY (LED) | Input Voltage, Output Power, Warning and Error Code |
| TRANSFER TIME | <30MS |
| TRANSFER RELAY RATING | 30A |
| MARKINGS | cETLus |
| CONFORMANCE | UL & CSA Standards |
| WEIGHT | 15.4 lbs |
| DIMENSION | 21.2 x 9.1 x 4.5″ |
