SL1204
The economical power solution for running tools, electronics and appliances that draw up to 400W.
The economical power solution for running tools, electronics and appliances that draw up to 400W.
Converts 12V battery power to 120V household AC power, the same as supplied by the local utility company. Ideal for running power tools, electronics and appliances flawlessly while away in your car, truck, boat, RV, remote home or cabin.
Features include:
Features And Benefits
Dimensions (L x W x H):
SL1204: 8.5” x 6.0” x 2.6” (216 x 151 x 65mm)
Weight:
SL1204: 2.4 lbs. / 1.1 Kg
| SL1204 SPECIFICATIONS | 120 VAC | SL1204 |
| AC Output | |
| AC Output Power (Continuous) | 400W |
| AC Output Power (Peak) | 800W |
| AC Output Voltage/Frequency | 120VAC / 60 Hz |
| AC Output Current | 3.3A |
| AC Output Waveform | True Sine Wave |
| Voltage (Nominal) | 12.5Vdc |
| Operation Range | 10.5 – 15.5Vdc |
| Inverter Standby Current | <0.8 |
| Input Undervoltage Shutdown | 10.5 Vdc |
| Input Overvoltage Shutdown | 15.5Vdc |
| Input Undervoltage Alarm | 11.0Vdc |
| Display Panel | |
| Indicator | Power / Fault |
| Remote Port | Yes |
| Ignition Status Port | Yes |
| Regulatory Compliance | |
| Markings | cETLus |
| Conformance | UL & CSA Standards |
| Enclosure | |
| Weight | 2.42 lbs. |
| Dimension | 8.5 x 6 x 2.6” |
| Accessory (Optional) | |
| Remote ON/OFF | Yes |
