MW1210
An economical power solution for running power tools and electronics that draw up to 1000 watts.
An economical power solution for running power tools and electronics that draw up to 1000 watts.
Converts 12V battery power to 120V household AC power and is ideal for running household electronics, appliances and power tools in your car, truck, boat or RV.
Features include:
Features and Benefits
Dimensions (L x W x H):
MW 1210: 6.0” x 3.0“ x 12.5” (152.4 x 76.2 x 317.5mm)
Weight:
MW 1210: 5.5 lbs. / 2.5 Kg
| MW SERIES (MODIFIED SINEWAVE) | MW1210 |
| POWER (CONTINUOUS) | 1000W |
| POWER (PEAK) | 2000W |
| VOLTAGE / FREQUENCY | 120 VAC / 60 Hz |
| CURRENT | 8.3A |
| WAVEFORM | Modified Sinewave |
| PEAK EFFICIENCY | 90% |
| AC OUTPUT SOCKET | NEMA 5-15 |
| 5V USB | 750mA |
| VOLTAGE (NOMINAL) | 12.5Vdc |
| OPERATION RANGE | 10.5 – 15.5Vdc |
| CURRENT (NO LOAD) | < 0.6A |
| INDICATOR (LED) | Status |
| DIGITAL DISPLAY | Input Voltage, Output Power, Warning and Error Code |
| INPUT UNDERVOLTAGE SHUTDOWN | 10.5Vdc |
| INPUT OVERVOLTAGE SHUTDOWN | 15.5Vdc |
| MARKINGS | cETLus |
| CONFORMANCE | UL & CSA Standards |
| WEIGHT | 5.3 lbs |
| DIMENSION | 12.3 x 6.9 x 3.4″ |
