AC1220
A multi-stage battery charger that charges up to three battery banks simultaneously with priority setting.
A multi-stage battery charger that charges up to three battery banks simultaneously with priority setting.
ABSO Product Line
KISAE’e Abso Chargers are smart, multi-stage 3-bank battery chargers that use advanced algorithms and safely replenish large capacity AGM, Gel, Flooded, and Lithium batteries to peak efficiency while improving battery life.
Features include:
AC 1220: 11.6” x 8.1“ x 3.4” (295 x 206 x 86mm)
AC 1220: 5.1 lbs. / 2.3 Kg
| BATTERY CHARGER | AC 1220 |
| OUTPUT RATING | |
| OUTPUT VOLTAGE | 12V |
| OUTPUT CURRENT (MAXIMUM) | 20A |
| DC OUTPUT | |
| SELECTABLE BATTERY TYPE | Gel, AGM, Flooded, Lithium, Program |
| CHARGE | 14.2 – 15.5V |
| FLOAT | 13.4 – 13.8V |
| EQUALIZE (FLOODED BATTERY ONLY) | 16.0V |
| CHARING CONTROL | Three / Two Stages, Program |
| DC OUTPUT BANK | Three |
| PARASITIC CURRENT | < 2 mA |
| AC INPUT | |
| AC INPUT VOLTAGE (NOMINAL) | 120, 230, 240VAC |
| AC INPUT OPERATING RANGE | 90 – 265VAC |
| AC INPUT FREQUENCY RANGE | 47 – 63Hz |
| POWER CONSUMPTION (FULL LOAD) | 350W |
| POWER FACTOR CORRECTION | YES |
| DISPLAY PANEL | |
| DIGITAL DISPLAY | LCD with back lighting |
| DIGITAL INFO | Voltage, Current, Status and Error Code |
| PROTECTION | |
| REVERSE BATTERY | YES |
| COOLING | Forced ventilation |
| OUTPUT SHORT CIRCUIT | YES |
| INGRESS PROTECTION | IP 32 |
| ENCLOSURE | |
| AC INPUT CONNECTION | Hardwire / AC Input Cord (Schuko, UK, Australia plug) |
| DC OUTPUT CONNECTION | Heavy Duty Studs |
| WEIGHT | 5.3 lbs |
| DIMENSIONS | 11.6 x 8.1 x 3.4″ |
